Construction

The TOUGH GUARD^™ series are new types of plated wires having corrosion resistance approximately five times that of conventional zinc aluminum alloys. TOUGH GUARD^™ FROST was developed exclusively as a base material of wire mesh for river bank protection. Soft steel wire rods with a rough surface do not easily slip.

This is a new type of stainless steel optimum for measures against tsunamis and water control measures such as dams, floodgates, and gates. The two-phase metallographic structure has achieved strength approximately twice that of the conventional type (SUS304). This is resource-saving stainless steel with less Ni and other alloy elements while its corrosion resistance is higher.

"U Column" is the product name for our large size square steel pipes (over 200-mm square) conforming to JIS G 3466 Carbon Steel Square and Rectangular Tubes for General Structure (STKR400 and STKR490). The available maximum size is 550-mm square with thickness of 22 mm. They are mainly used as studs of steel-frame buildings as well as for roof trusses, bridges, and construction and industrial machinery.Various major international standards, such as ASTM, CSA, EN, AS are available.

Square steel pipes (smaller than 200-mm square) conform to JIS G 3466 Carbon Steel Square and Rectangular Tubes for General Structure (STKR400 and STKR490). They can be used as building components and for frames of construction and industrial machinery and for many other application purposes. In addition to black pipes, colored square pipes for which coating has been applied as primary rustproofing are provided. "Eco-Kaku", square steel pipes with thinner walls compared to those of conventional square pipes are also available.Various major international standards, such as ASTM, CSA, EN, AS are available.

NSMP Deck Plates made its debut in Kasumigaseki building, the world's first quake-proof skyscraper. Since then, we have been giving careful attention to customer requests and we have been improving and refining our deck plates and developing new types to satisfy various needs, providing products optimum for each use.

As the series of NSMP Roof Decks, UA-R, a new type of deck plate with narrower ditches and higher walking safety, joined our product line-up, following Super E deck and HYPERDECK^™. This enrichment in our product line-up remarkably improves the external insulation roof construction method using deck plates as beds. NSMP Roof Decks are applied to a wide range of applications for roofs.

Cynos Decks have the floor quality of "slabs with equal thickness" while the "deck composite slab structure" is highly economical compared to other construction methods, satisfying high levels of demand for vibration and sound insulation performance. They can be flexibly constructed at actual construction sites similar to conventional deck plates, for example, they can be cut and welded at actual sites. Connecting decks to partition walls has been made easier, which contributes to saving labor.

Flat decks for high loads and long spans. The height of the ribs was reduced to 90 mm by revising the shape of upper flanges. The cross-sectional performance has been improved even when compared to products with 100-mm ribs height,with lighter weight. The adoption of the sliding method in which ribs are engaged and the elimination of adjustment decks enhances the work efficiency at actual construction sites and contributes to enhancing the safety.

Laminated metal sheets for which NIPPON STEEL SuperDyma^™ highly corrosion-resistant coated steel sheets is used as the base material and Tedlar^™ the only one type of 100% fluororesin film¾is used as film. They are highly resistant to sunlight, acid, alkali, and salt damage. They are used for roofs, walls, and many other applications in severe environments such as in coastland and industrial zones.

“Colxam^™ series” is color coating stainless steel sheets of NSSC^™ brand proposing comfortable living spaces.
The base material is made of stainless steel, which is highly durable.

A footbridge using duplex stainless steel as the main material featuring high strength and high corrosion resistance. Duplex stainless steel makes re-coating maintenance of the bridge unnecessary and contributes to reduction in life-cycle cost. In particular, it achieves no maintenance in environments where salt damage is a problem.

Exterior material for bridges using metal skin material (3 types: titanium, stainless steel, and coated steel sheet) with high corrosion resistance. The bridge is protected from external corrosion factors such as wind/rain, solar radiation, salt, etc. and a high corrosion preventive function protecting from corrosion factors such as condensation greatly extends the period until re-coating. In this way, the maintenance cost can be reduced. Since the panel itself has strength, it can be used as a scaffold to perform safe and definite short-range visual inspection.

New-type metal slab bridge using square piping for a short-span bridge (within 15 m) as the main girder. In comparison with the PC bridge, substructure reaction is reduced by about 20% to make the substructure compact. Since the girder height is low, the existing substructure can be reused when the superstructure is renewed and it is suitable for bridges on rivers in cities, and bridges having multi-level crossings with main roads or railways. Panels are produced in a factory and built on the site. Construction is fast and simple and construction in narrow places can be performed with a heavy machine.

A water supply channel is an important facility for water business. Most of the piping is buried under the ground. In crossing rivers, the presence is shown as a water pipe bridge. It is necessary to be safe under all conditions and to be functional over a long period of time. An esthetic element that has good harmony with the construction environment is also an important item.
